Alpine S-Series 1-Inch Type-S Cloth Dome Tweeter Set, 80-Watts RMS
Don’t let the compact size fool you. The S2-S10TW tweeters are engineered to add clarity and detail to your sound system. By accurately reproducing the upper frequencies, these 1-inch tweeters enhance vocals, instruments, and subtle details that most factory systems miss. With every note and nuance, you’ll rediscover your music and experience your favorite songs like it’s the first time.
Compared to the previous generation, the S2-S10TW features an improved dome shape and tweeter assembly for better control and a smoother dynamic range. A newly designed silhouette-style grille and enhanced wave guide work together to widen sound dispersion and create a more natural, immersive soundstage.
The S2-S10TW includes a small, in-line crossover made of high-grade electrical components that seamlessly rolls off your midrange while also passively protecting your tweeters from low frequency damage. The small size of the crossover also makes installation fast and convenient.
Features
1” cloth dome tweeter.
Hi-Res Audio certified (up to 40kHz).
80W RMS / 240W Peak power handling.
Updated dome design (compared to S-S10TW) for improved control and smoothness.
Enhanced wave guide for wider dispersion.
New silhouette-style grille design.
Swivel flush-mount design.
Removable housing for tight factory locations.
Compact size: 2” cutout, ¾” depth.
4-ohm impedance for easy integration.
Delivers clear, accurate high frequencies.
Designed for use with Alpine S-Series component systems.
Ideal factory tweeter upgrade.
Specifications
1" (2.5cm) Component Tweeter.
80W RMS / 240W Peak Power.
4 Ohm Impedance.
Frequency Response: 1kHz – 40kHz.
Sensitivity: 87dB SPL (1W @ 1m).
Cutout Diameter: 2" (5.1cm).
Mounting Depth: 3/4" (1.8cm).
Swivel Flush Mount Housing.
Cloth Dome Tweeter Material.
Removable Mounting Housing for Custom Installs.
C1-Series 0.75-Inch Aluminum Dome 60-Watt Tweeters.
C1 component tweeters are engineered to deliver refined performance, with excellent off-axis response and high-frequency extension. Utilizing true, edge driven 0.75-inch aluminum domes with silk suspensions, the C1-075ct component tweeters provide smooth, detailed reproduction of treble frequencies from 4 – 24 kHz.
The tweeters can be flush-mounted or surface-mounted with the supplied fixtures to fit a wide variety of installation needs. Inline, outboard, 12 dB / octave, high-pass filters are included to ensure smooth response and reliability. These fliters also are equipped with Advanced Tweeter Protection Circuitry to improve power handling and reliability.
When it comes to value, C1 is the real deal!
Sold as a pair. Surface-mount and flush-mount fixtures and grilles are included.
General Specifications
Continuous Power Handling (RMS)
50 W
Peak Music Power*
150 W
Recommended Amplifier Power (RMS)
20 - 50 W / Ch.
System Efficiency
91.0 dB @ 1 W / 1 m
System Nominal Impedance
6 Ω
System Frequency Response
4 kHz - 24 KHz ± 3 dB
Documentation
JL Audio C1-075ct Manual
C1-Series 1-Inch Aluminum Dome 60-Watt Tweeters.
C1 component tweeters are engineered to deliver refined performance, with excellent off-axis response and high-frequency extension. Utilizing true, edge driven 1.0-inch aluminum domes with silk suspensions, the C1-100ct component tweeters provide smooth, detailed reproduction of treble frequencies from 3.6 – 22 kHz.
The tweeters can be flush-mounted or surface-mounted with the supplied fixtures to fit a wide variety of installation needs. Inline, outboard, 12 dB / octave, high-pass filters are included to ensure smooth response and reliability. These fliters also are equipped with Advanced Tweeter Protection Circuitry to improve power handling and reliability.
When it comes to value, C1 is the real deal!
Sold as a pair. Surface-mount and flush-mount fixtures and grilles are included.
General Specifications
Continuous Power Handling (RMS)
60 W
Peak Music Power*
150 W
Recommended Amplifier Power (RMS)
20 - 60 W / Ch.
System Efficiency
91.5 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
3.6 kHz - 22 KHz ± 3 dB
Documentation
JL Audio C1-100ct Manual
C2-Series 0.75-Inch 60-Watt Silk Dome Tweeters.
The silk dome tweeter is prized by audiophiles for delivering realistic, non-fatiguing, high-frequency performance.
The C2 component tweeters are built with 0.75-inch silk dome diaphragms that deliver powerful, extended response, on and off axis. Flush-mounting and surface-mounting fixtures are included to fit a wide variety of installation needs.
Inline 12 dB / octave high-pass filters with tweeter protectors are included with this kit. The C2-075ct is designed to operate above 4 kHz with a minimum high-pass slope of 12 dB / octave.
Sonic character: Clean and Powerful
Sold as a pair.
General Specifications
Continuous Power Handling (RMS)
60 W
Peak Music Power*
150 W
Recommended Amplifier Power (RMS)
25 - 100 W / Ch.
System Efficiency
91.0 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
4 kHz - 22 KHz ± 3 dB
Documentation
JL Audio C2-075ct Manual
C3-Series 1-Inch 75-Watt Pair of Silk Dome Component Tweeters
The silk dome tweeter is prized by audiophiles for delivering realistic, non-fatiguing, high-frequency performance.
The C3 component tweeters are built with 1-inch silk dome diaphragms that deliver powerful, extended response, on and off axis. Flush-mounting and surface-mounting fixtures are included to fit a wide variety of installation needs. They can also be installed coaxially onto the C3 woofers using the fixtures included with the C3 Component / Coaxial Systems.
Inline 12 dB / octave high-pass filters with tweeter protectors are included with this kit. The C3-100ct is designed to operate above 4 kHz with a minimum high-pass slope of 12 dB / octave.
Sonic character: Clean and Powerful
Sold as a pair.
General Specifications
Continuous Power Handling (RMS)
75 W
Peak Music Power*
225 W
Recommended Amplifier Power (RMS)
25 - 150 W / Ch.
System Efficiency
90.0 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
4 kHz - 25 KHz ± 3 dB
Documentation
JL Audio C3-650 Manual
C6-Series 1-Inch 75-Watt Single Silk Dome Component Tweeter.
Born from the same DNA as the JL Audio flagship C7 speakers, the C6 series component drivers let you team premium, pure silk dome tweeters with highly linear woofers to create a loudspeaker system of exceptional refinement, precision and dynamic capability.
Pairing full-frame 6.5-inch or 2.75-inch woofers with 1-inch silk dome tweeters, the C6 series drivers offer advanced sound technology for an exceptional car audio listening experience. Passive crossover networks are not included with the C6 drivers, as they are designed for active systems.
An edge-driven pure silk dome tweeter design, when paired with the C6 woofer, produces sparkling detail with excellent off-axis response and damping for balanced coverage in your listening environment. An automatic, solid-state tweeter protection circuit minimizes the possibility of tweeter failure.
A high-quality tuning Digital Signal Processor (DSP) — such as the TwK® DSP or a VXi amplifier with built-in DSP — is recommended. Using individual amplifier channels for each C6 speaker enables the system designer to achieve precise setup of equalization, delay and crossover filters for optimal in-vehicle performance.
Sold as a single tweeter.
General Specifications
SIZES
1", 2.75", 6.5"
CONTINUOUS POWER HANDLING (RMS)
1": 75W, 2.75": 50W, 6.5": 100W
SENSITIVITY (SPL @ 1 W/1 M)
1": 90dB, 2.75": 83.50dB, 6.5": 87.37dB
SENSITIVITY (SPL @ 1 W/0.5 M)
1": 96dB
SENSITIVITY (SPL @ 2.83 V/1 M)
1": 93dB, 2.75": 86.50dB, 6.5": 90.33dB
FREQUENCY RESPONSE (+/- 3 DB)
1": 3kHz-21KHz, 2.75": 350 Hz-4.KHz, .5": 55Hz-6KHz
NOMINAL IMPEDANCE
4 Ω
RECOMMENDED AMPLIFIER POWER (RMS)
1": 25-100W Channel, 2.75": 25-80W Channel, 6.5": 25-150W Channel
VOICE COIL DIAMETER
2.75": 0.8" (20.5mm), 6.5": 1.27" (32mm)
CONE MATERIAL
Vacuum-formed, mineral-filled polypropylene
TWEETER TYPE
Silk Dome
TWEETER SIZE
1" (25mm)
GRILLE(S) INCLUDED
yes
WARRANTY
1 year
CONNECTIONS
SPEAKER CONNECTIONS
Spade connectors
MOUNTING DIMENSIONS
FRAME OUTER DIAMETER
2.75": 2.52" (77mm), 6.5": 6.5" (165mm)
MOUNTING DEPTH CLEARANCE
2.75": 1.42" (36mm), 6.5": 2.60" (66mm)
FRONTAL GRILLE PROTRUSION
2.75": 0.47" (12mm), 6.5": 1" (25mm)
MOUNTING HOLE
2.75": 2.52" (64mm), 6.5": 5.46" (139mm)
GRILLE TRAY OUTER DIAMETER
2.75": 3.58" (91mm), 6.5": 6.76" (172mm)
BOLT HOLE CIRCLE
2.75": 3.03" (77mm), 6.5": 6.12" (156mm)
MOTOR OUTER DIAMETER
2.75": 2.75" (69mm), 6.5": 3.54" (90mm)
PARMETERS
FREE AIR RESONANCE (FS)
1": 1500Hz, 2.75": 185Hz, 6.5": 52.8Hz
ELECTRICAL “Q” (QES)
2.75": 0.769, 6.5": 0.647
MECHANICAL “Q” (QMS)
2.75": 7.848, 6.5": 5.076
TOTAL “Q” (QTS)
2.75": 0.700, 6.5": 0.574
EQUIVALENT COMPLIANCE (VAS)
2.75": 0.0353 cu ft (0.125L), 6.5": 0.532 cu ft (15.069L)
ONE-WAY LINEAR EXCURSION (XMAX; SPECS ARE DERIVED VIA ONE-WAY VOICE COIL OVERHANG METHOD WITH NO CORRECTION FACTORS APPLIED)
2.75": 0.059" (1.50mm), 6.5": 0.148" (3.75mm)
REFERENCE EFFICIENCY (NO)
1": 0.602%, 2.75": 0.1414%, 6.5": 0.344%
MOVING MASS (MMS)
2.75": 4.65g, 6.5": 16.42g
MECHANICAL COMPLIANCE (CMS)
2.75": 0.00031 m/N, 6.5": 0.000581 m/N
MAGNETIC STRENGTH (BL)
2.75": 5.03, 6.5": 5.186
EFFECTIVE PISTON AREA (SD)
2.75": 3.66 in² (0.00236m²), 6.5": 21.4 in² (0.013807m²)
DC RESISTANCE (RE)
1" & 6.5": 3.20Ω, 2.75": 3.58Ω
TWEETER SPECS
FLUSH MOUNT FIXTURE DIAMETER
1": 2.13" (54mm)
SURFACE MOUNT FIXTURE DIAMETER
1": 2.11" (54mm)
FLUSH MOUNT MOUNTING HOLE DIAMETER
1": 1.85" (47mm)
FLUSH MOUNT MOUNTING DEPTH
1": 1.85" (47mm)
FLUSH MOUNT TWEETER FRONTAL PROTRUSION
1": 0.30" (8mm)
SURFACE MOUNT TWEETER FRONTAL PROTRUSION
1": 1.04" (26mm)
Documentation
JL Audio C6-100ct Manual
C7-Series 1-Inch 100-Watt Aluminum Dome Component Tweeter.
C7 is the pinnacle of JL Audio automotive loudspeaker design, benefiting from their most advanced development tools and a complete commitment to precision manufacturing.
The C7-100ct component tweeter is designed to deliver unparalleled high-frequency performance. Utilizing a corundum ceramic-coated aluminum alloy diaphragm suspended via a treated silk, s-roll surround, it provides spectacularly detailed reproduction of treble frequencies with outstanding off-axis response. Distortion and non-linearities have been minimized through critical optimization of dynamic motor and suspension behaviors.
Passive crossover networks are not included with C7 drivers, as they are designed for active systems. Instead, we recommend a high-quality tuning DSP, such as the JL Audio TwK™ 88 or D8, and a dedicated amplifier channel for each C7 loudspeaker in the system. Precise setup of equalization, delay and crossover filters will ensure optimal in-vehicle performance.
Corundum ceramic coated aluminum alloy diaphragm exhibits high stiffness, very low mass and excellent environmental stability. It also helps the tweeter dome to hold its shape and operate as a true piston at higher frequencies, without a penalty in moving mass.
The diaphragm's motion is centered, sprung and damped by a treated silk, s-roll surround. Ferrofluid in the magnetic gap acts as a rear suspension element in this design. The two combine to provide optimum damping without unduly restricting excursion.
The C7-100ct employs a high-density magnetic circuit with a neodymium magnet and U-Yoke motor topology. An under-hung voice coil is employed, wound with copper-clad aluminum wire onto an aluminum voice coil former. Motor magnetics have been precisely optimized utilizing advanced FEA tools to lower even order distortion and IMD/AMD.
The shape of the tweeter housing is designed to boost sensitivity in a very specific bandwidth, helping to flatten the frequency response. It also provides improved control of directivity.
With 48 dB/octave filters: 3,000 Hz - 30,000 HzWith 24 dB/octave filters: 4,000 Hz - 30,000 HzWith 12 dB/octave filters: 5,000 Hz - 30,000 Hz
Sold individually, with flush and surface mounting fixtures and hardware. One 15μF tweeter protection capacitor is also included.
The performance of every C7 driver is tested and verified, then assigned a unique serial number. Register your C7 loudspeaker online to receive a copy of its specific Acoustical Test Report.
General Specifications
Continuous Power Handling (RMS)
100 W
Peak Music Power
200 W
Recommended Amplifier Power (RMS)
50 - 150 W / Ch.
Nominal Impedance
4 Ω
Frequency Response
3 kHz - 30 KHz ± 3 dB
Documentation
JL Audio C7-100ct Manual
Replacement Tweeter Adapter Mounting Plates for Select 2021-UP Ford Bronco Vehicles.
Upgrade your Ford Bronco dash speakers with the help of these Dash-Mount Tweeter Plates. These plates are sold as a pair and are designed for the installation of 2.5” speakers. They mount directly into the factory location so there is no drilling required.
Features:
For installation of 2.5” tweeter speakers into the factory dashboard
Sold as a pair
Applications
FORD
Bronco
2021-2023
Bronco Sport
2021-2023
2-1/2-Inch Replacement Dash-Tweeter Adapter-Plate for Select 2022-UP Toyota Vehicles.
Upgrade your Toyota’s speakers with the help of these speaker adapter plates. These adapters are sold as a pair and designed to install an aftermarket tweeter or small mid-range in multiple vehicle applications, making them convenient to have on hand. They mount directly into the factory dashboard location, so no drilling is required, making for easy installation.
For the installation of an aftermarket tweeter or small, mid-range speakers in the original factory dashboard location
Front Tweeter Applications
TOYOTA
Sequoia
2023-2024
Tundra
2022-2024
